Application

Draining steam, gas and fluid spaces Ideal for draining pipes

Function

Increasing level opens and decreasing level closes the outlet without delay, independent of pressure and temperature fluctuations

Special characteristics

The rotary slide valve is both swivel joint and shut-off device Proportional control behaviour

Fast-reacting for hot and cold media

Venting

Operating at steam requires additional venting device: Manually via control screw

Vent jet

Thermal venting device

Additional equipment:

Drain plug

Reflective water level sight glass Non return valve

Check valve

Different thermal venting devices

Application examples

Draining compressed air and pressurized gas systems, heat exchangers and steam distributers

Draining main lines
